IEC60529 IPX3 IPX4 Waterproof Tester / IPX3 / IPX4 Oscillating Spray Tester
  • prev
  • Next


IEC60529 IEC60335 IPX3 IPX4 Water Spray Test chamber


The rain test system is strictly designed according to IEC60529. It’s applied to the Electrical equipment of the waterproof test of IPX3 and IPX4.

Technology Parameter

Power Supply

Single phase: AC220V, 50Hz

Swing Pipe diameter

19mm, thickness 2mm

Swing Pipe radius

R800 (304 stainless steel)

Orifice diameter


Orifice angle

IPX3: 120°;

IP4X: 180°

Pendulum Angle

IPX3: 120°(±60°);

IPX4: 360°(±180°)

Swing Pipe Speed

EPX3: 4s/time (2x120°)

IP4X: 12s/time (2x180°)

Water discharge

1-10L/min, adjustable

Test time

0-999mins, can preset

Swivel table diameter


Swivel table speed

(1-5) rpm

Tiltable Angle


Swivel table rotation angle

900°,continuous rotation

Pressure Gage


The tubes oscillate to almost 180 ° either side of vertical. The degree of oscillation can be set on the touch screen controller or one of the three pre-set values, 90 ° , 120 ° , or almost 180 ° , can be selected.

A specimen support is also included. It is supplied with two specimen bases - one perforated for IPX4 and one non-perforated for IPX3. The support is made from stainless steel and mounted on wheels for easy maneuverability and adjustment. It offers height adjustments that range from 855mm to 1300mm. The oscillating tubes are manufactured with orifice radii of 200 mm to 1600 mm with a progressive ratio of 200 mm.
